DROK DC Motor Driver, L298 Dual H Bridge Motor Speed Controller DC 6.5V-27V 7A PWM Motor Regulator Board 12V 24V Electric Motor Control Module Industrial 160W with Optocoupler Isolation

Brand: DROK
  • DROK DC motor driver input voltage range is DC 6.5V-27V, can be input DC 12V or 24V, rated output current of each port is 7A, total output power is 160W.
  • STRONG DRIVE: the motor controller board adopts dual H bridge, can drive two DC motors at the same time.
  • FORWARD and REVSERSELY ROTATE: the IN1, IN2/IN3, IN4 port can control forward or reverse motor rotation.
  • PWM SPEED CONTROL: enable signal terminal (ENA) input PWM can regulate speed, PWM frequency range 0-10KHZ.
  • UNDER VOLTAGE PROTECTION: the motor driver module is with under voltage protection to prevent instantaneous large current from damaging the module.
Brand: DROK
Size: Dual H Bridge Motor Controller 7A
Manufacturer: DROK
Part Number: XGD5SCB
Model: 200206_OZ
Material Type: Metal
Product Dimensions: 1.1 x 3.66 x 3.94 inches; 1.44 ounces
Isin: IQFIMHX3PIVF

$36.57

  • Free shipping in US
  • Shipping: $6.5 Standard Shipping (5-10 Business Days)
  • Arrives:

  • Free 30-Day returns

In Stock

Sold by , Fulfilled by IBSPOT
Ships from USA

IBspot Buyer Protection

Shop confidently on IBspot, receive your item as described or your money back for eligible orders. Learn Program Terms

supported payment methods:Visa, Mastercard, Discover, Amex, Apple Pay, Google Pay

GUARANTEED SAFE CHECKOUT

More seller options

Starting from

Compare all sellers
  • MONEY BACK GUARANTEE

    30 days money back guarantee, no additional fee charged.

  • EXCELLENT SUPPORT

    We provide 24/7 online customer support via email.

  • Fast Shipping

    One week domestic shipping. Global delivery to the US in 2 weeks.

scroll to top arrow
DROK DC Motor Driver, L298 Dual H Bridge Motor Speed Controller DC 6.5V-27V 7A PWM Motor Regulator Board 12V 24V Electric Motor Control Module Industrial 160W with Optocoupler Isolation

DROK DC Motor Driver, L298 Dual H Bridge Motor Speed Controller DC 6.5V-27V 7...

$36.57

Parameters:
1. Power supply voltage 6.5V-27V, the power cannot be reversed or over 27V, or may burn the module, it is recommended connecting in series 15A fuse in the power input.
2. Dual motor interface, each rated output current 7A, peak current 50A, the motor interface cannot short-circuit, it is recommended connecting in series 15A fuse.
3. The enable signal and forward and reverse control signal control voltage 3-6.5V.
4. Enable signal terminal (ENA) input PWM can regulate speed, PWM frequency range 0-10KHZ, PWM minimum pulse width 10us.
5. Product dimension: 55x55x16mm
6. Installation hole diameter: 3mm, noted to prevent short circuit when install the reverse side, you can add insulation pad or copper column to raise the circuit board

Parameters matched:
Motors with rated voltage 24V, identification of rated power 115W or below, and motors with identification of rated current 7A can full work for a long time.

Note:
1. Drive power cannot be reversed, it is recommended connecting in series 15A fuse in the power interface, the voltage should be between 6.5 - 27V. If over voltage, it may burn the drive module if power on.
2. It is recommended that the rated output current of the power supply be more than 2 times, in case the power supply voltage cannot reach the required input voltage of the motor when it is started, which   may cause pause of the drive module for under voltage protection.
3. Motor interface cannot be short-circuit, or may burn the drive module, it is recommended connecting in series 10A fuse in the motor interface.

Package Including:
1x DC Motor Driver Board
