ZONADAH Long Range Remote AB Buttons Remote Control Digital Remote Control Motor Switch Controller For Linear Current 433MHz Led Light Remote Control
ZONADAH Long Range Remote AB Buttons Remote Control Digital Remote Control Motor Switch Controller For Linear Current 433MHz Led Light Remote Control
ZONADAH Long Range Remote AB Buttons Remote Control Digital Remote Control Motor Switch Controller For Linear Current 433MHz Led Light Remote Control
Product Overview
- Wireless Freedom: Embrace the convenience of wireless control with the ZONADAH Remote. Operating on a stable 433MHz frequency, it effortlessly penetrates walls, floors, doors, and windows, offering unparalleled control flexibility. You can use multiple units simultaneously in the same location without interference.
- Extended Range: With a reference distance of 100 meters in open spaces, this remote control ensures that you can command your devices from a considerable distance. Experience the freedom to operate your appliances or equipment conveniently, even when you're not in close proximity.
- Versatile Operating Modes: The ZONADAH Remote Control boasts various operating modes, including instantaneous response, self-locking, interlocking, and a convenient delay feature. Whether you need quick actions or a timed response (5-second delay), this remote has you covered.
- Dual-Channel Control: With two channels for control, you can effortlessly manage multiple devices or functions using a single remote. Toggle between working modes, from instantaneous control to toggling, latching, or a 5-second delay, providing adaptability for various applications.
- High Sensitivity and Outstanding Performance: Precision-crafted with high sensitivity, the ZONADAH Remote ensures exceptional performance across diverse environments. Its robust wireless RF technology guarantees reliability, making it an ideal choice for home and industrial applications.
| Brand: | ZONADAH |
|---|---|
| Manufacturer: | ZONADAH |
| Part Number: | QY63BT3 |
| Isin: | IL75CPSMXGQU |
Out of Stock
In Stock
Backordered
Out of Stock
IBspot Buyer Protection
Shop confidently on IBspot, receive your item as described or your money back for eligible orders. Learn Program Terms
Product Overview
- Wireless Freedom: Embrace the convenience of wireless control with the ZONADAH Remote. Operating on a stable 433MHz frequency, it effortlessly penetrates walls, floors, doors, and windows, offering unparalleled control flexibility. You can use multiple units simultaneously in the same location without interference.
- Extended Range: With a reference distance of 100 meters in open spaces, this remote control ensures that you can command your devices from a considerable distance. Experience the freedom to operate your appliances or equipment conveniently, even when you're not in close proximity.
- Versatile Operating Modes: The ZONADAH Remote Control boasts various operating modes, including instantaneous response, self-locking, interlocking, and a convenient delay feature. Whether you need quick actions or a timed response (5-second delay), this remote has you covered.
- Dual-Channel Control: With two channels for control, you can effortlessly manage multiple devices or functions using a single remote. Toggle between working modes, from instantaneous control to toggling, latching, or a 5-second delay, providing adaptability for various applications.
- High Sensitivity and Outstanding Performance: Precision-crafted with high sensitivity, the ZONADAH Remote ensures exceptional performance across diverse environments. Its robust wireless RF technology guarantees reliability, making it an ideal choice for home and industrial applications.
| Brand: | ZONADAH |
|---|---|
| Manufacturer: | ZONADAH |
| Part Number: | QY63BT3 |
| Isin: | IL75CPSMXGQU |
ZONADAH Remote Control: Elevate Your Control Experience
Introducing the ZONADAH Remote Control, a versatile and reliable solution crafted with precision from high-quality ABS and PC plastics. This remote control sets itself apart with five key features, delivering a seamless and efficient control experience for various applications.
Specifications:
- Material: ABS+PC Plastic
- Operating Voltage: DC 6V
- Operating Current: ≤12mA
- Operating Frequency: 433MHz
- Reference Distance: 100 meters (Open Space)
- Modulation Method: ASK
- Dimensions: 60mm x 31mm x 11mm
- Encoding Method: 1527 Learning Code
- Package: 1 x Remote Control
Experience unparalleled convenience and control with the ZONADAH Remote Control. From lighting and motors to fans, doors, and windows, this remote is the versatile solution for all your household and industrial electrical devices.
Instructions:
Clear Pairing:
(Before switching modes, clear the pairing first)
Press the learning button 9 times. The LED will turn off. The LED will flash 5 times, indicating the clear operation is successful.
(If you need to change the working mode of the same remote, please clear the pairing first and then re-learn.)
Pairing:
Momentary Function:
Press the pairing button on the control board once. The LED indicator will flash once, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Self-locking Function:
Press the pairing button on the control board twice. The LED indicator will flash twice, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Interlocking Function:
Press the pairing button on the control board three times. The LED indicator will flash three times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
5-second Delay Learning Method:
Press the pairing button on the control board four times. The LED indicator will flash four times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
10-second Delay Learning Method:
Press the pairing button on the control board five times. The LED indicator will flash five times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
15-second Delay Learning Method:
Press the pairing button on the control board six times. The LED indicator will flash six times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
20-second Delay Learning Method:
Press the pairing button on the control board seven times. The LED indicator will flash seven times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Power-on Function Learning Method:
Press the pairing button on the control board eight times. The LED indicator will flash eight times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
(This function means the relay automatically pulls in after power is applied, also known as the "power-on light" function.)
Note: Please check the wiring method carefully to avoid short circuits.
Introducing the ZONADAH Remote Control, a versatile and reliable solution crafted with precision from high-quality ABS and PC plastics. This remote control sets itself apart with five key features, delivering a seamless and efficient control experience for various applications.
Specifications:
- Material: ABS+PC Plastic
- Operating Voltage: DC 6V
- Operating Current: ≤12mA
- Operating Frequency: 433MHz
- Reference Distance: 100 meters (Open Space)
- Modulation Method: ASK
- Dimensions: 60mm x 31mm x 11mm
- Encoding Method: 1527 Learning Code
- Package: 1 x Remote Control
Experience unparalleled convenience and control with the ZONADAH Remote Control. From lighting and motors to fans, doors, and windows, this remote is the versatile solution for all your household and industrial electrical devices.
Instructions:
Clear Pairing:
(Before switching modes, clear the pairing first)
Press the learning button 9 times. The LED will turn off. The LED will flash 5 times, indicating the clear operation is successful.
(If you need to change the working mode of the same remote, please clear the pairing first and then re-learn.)
Pairing:
Momentary Function:
Press the pairing button on the control board once. The LED indicator will flash once, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Self-locking Function:
Press the pairing button on the control board twice. The LED indicator will flash twice, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Interlocking Function:
Press the pairing button on the control board three times. The LED indicator will flash three times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
5-second Delay Learning Method:
Press the pairing button on the control board four times. The LED indicator will flash four times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
10-second Delay Learning Method:
Press the pairing button on the control board five times. The LED indicator will flash five times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
15-second Delay Learning Method:
Press the pairing button on the control board six times. The LED indicator will flash six times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
20-second Delay Learning Method:
Press the pairing button on the control board seven times. The LED indicator will flash seven times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
Power-on Function Learning Method:
Press the pairing button on the control board eight times. The LED indicator will flash eight times, then stay on. After the LED indicator is on, press the button on the remote control that needs to be paired. The LED on the control board will flash three times continuously, indicating successful pairing.
(This function means the relay automatically pulls in after power is applied, also known as the "power-on light" function.)
Note: Please check the wiring method carefully to avoid short circuits.
